Technical Descriptions

• Maximum Operating pressure: 2000 bar
• Upto 9 injections per cycle
• Solenoid actuated 2-way control valve with low inertia
• Axial 19mm body and stepped capnut
• 2-way Electrical connection
• Nozzle: micro-sac, up to 8 injection holes
• Corrosion protection: Phosphate type deposit on Capnut and NHB
• High reliability package
• Valve Robustness package to deposit and negative back pressure running package

Customer Advantages

• Low voltage activation allows simpler, reliable and cost effective electronic design
• Optimized injection rate
• Rail pressure discharge capability enables HPV removal
• End Of injector assembly Line I3C characterization process for lower quantity scatter
• Small quantity learning for pilot & main low scatter & better noise/emission trade-off

Technical Descriptions

• Max Operating Pressure: 2000 bar
• Forged tubular rail
• Cataphoretic painting applied before machining
• M14 x 1.5 mm HP outlet & inlet
• 2 x ID 9 mm fixations pads
• High Pressure Sensor
• Optional Pressure Limiting Valve

• Orifice on HP Outlets

Customer Advantages

• Low Mass
• Optimized Hydraulic for all HP inlet and outlet

Technical Descriptions

• Designed for medium and high spec Eu6/BS6 application
• 196 pins arranged in 2 cavities
• 12V Capable with 28V Boost
• 32bit Multi-core microprocessor @ 200MHz
• 4 to 8MB Flash ROM
• 472K RAM

• Chassis mount
• Lead free soldering
• Under bonnet with IP6K9K sealing protection with connector
• Ambient -40°C to 105°C
• Chassis / body mounting
• Supports DPF / LNT / SCR with OBD2 functions
